CAST Navigation - Portable Dual Frequency GPS Simulator
DETAIL
The CAST-1000 is capable of generating a full constellation of GPS with 8 to 12 satellites in view selected from the
defined 32 Pseudo Random Noise codes. It generates signals for 8 to 12 satellites of C/A Code on L1 and P Code
on L1 and L2.
System Features
• Up to 12 C/A and P Code SVs on L1 and L2
• 6-DOF Motion Generation Capability
• Selectable Host Vehicle Parameters
• Complete SV Constellation Editing
• External Ephemeris and Almanac Loading
• Spoofer Simulation
• Satellite RAIM Events
• Ionosphere and Troposphere Modeling
• Satellite Clock Errors
• Waypoint Navigation
• Multipath Modeling
• Modifiable Navigation Message
• Time-tagged Satellite Events
• Models Selective Availability
• Antenna Pattern Modeling
• External Trajectory Input
• Post Mission Processing
Output Signal Types
• GPS L1 1575.42 MHz
• GPS L2 1227.60 MHz
• GPS L5 1176.45 MHz
Maximum Dynamics
• Velocity > 60,000 m/s
• Acceleration ± 150,000 m/s2
• Jerk ± 150,000 m/s3
Signal Output Levels (Nominal)
• GPS L1 C/A Code -160 dBW
• GPS L1 P Code -163 dBW
• GPS L2 P Code -166 dBW
