Radar simulator- Compact
Radar simulator- Compact
INTERSOFT - The RTG (Radar Target Generator) synthetically generates primary radar returns based on user requirements,
providing a high-fidelity simulation of real targets to enable the development and performance of precise test
scenarios。
providing a high-fidelity simulation of real targets to enable the development and performance of precise test
scenarios。
DETAIL
Product Highlights -
A correct Doppler is guaranteed on all frequencies, even in agile mode. This is advantageous on radar systems that resolve the Doppler ambiguity on different frequencies.
The computer with associated application software is built in the 19-inch enclosure of the RTG.Interfacing is done with a network cable. The built-in computer has two network connectors and can easily be controlled over a remote desktop connection.
Serial inputs enable UTC timestamping (NMEA protocol) from either a time server or from a GPS.The RTG can measure the frequency of the received pulses, which provides more accurate output power more because the output power is equalized vs frequency.
An available correction table enables the user to enter the cable losses of the setup versus frequency.
Output power can be modulated according to the received input power (adaptive beam modulation),even when the radar operates with frequency agility.
