GNSS simulator

GNSS simulator

CAST Navigation - Multi-Constellation GNSS RF Signal Generation Technology
DETAIL
Datasheet Download : GNSS Modeling and Simulation

System Features
• Provides precise and repeatable GNSS RF signals that can be utilized for testing in a laboratory or field-type environment

• Signal types supported: GPS, BeiDou GLONASS,SBAS

• Systems are capable of simulating either static or dynamic motion for terrestrial, aquatic, airborne and space-based vehicles

• Customizable solutions allow confi gurations of GNSS signals to meet your requirements

• Incorporates years of development, testing, and refinement of the precise GNSS/INS synchronization capability needed
   for simulation of aircraft dynamics

Output Signal Types
• GPS: L1, L2, L2C, L5, C/A-Code, P-Code,Y-Code,
• SAASM, M-Code AES, M-Code MNSA
• BeiDou: BDS-B1L, BDS-B1C
• GLONASS: L1, L2
• SBAS: WAAS, EGNOS, MSAS, GAGAN

Maximum Dynamics
• Velocity: > 60,000 m/s
• Acceleration: ± 150,000 m/s2
• Jerk: ± 150,000 m/s3

Signal Output Levels (Nominal)
• GPS: -160 dBW
• GLONASS: -161 dBW
• Beidou: -163 dBW
• SBAS : -160 dBW
